XR35-Series Trencher Requires 20-45 GPM 2,000-4,200 PSI | Lowe
lowe-xr35
limited quantity available
LIMITED TIME FREE SHIPPING!
5% discount applied.
Sale ends December 31, 2024
DETAILS
Discover the Lowe XR35-Series Skid Steer Trencher Attachment – the ultimate choice for high-performance trenching. Engineered for power and efficiency, this heavy-duty trencher attachment is designed to tackle the toughest trenching jobs with ease. Equipped with a robust 50,000 lb. (22,680 kg) digging chain and a removable double-flighted spoil auger, it ensures faster, cleaner trenching. Key design upgrades include a self-aligning boom with a grease cylinder tensioning system, maintenance-free tapered roller bearings, a durable boom roller, and advanced high-pressure operation. Choose the center trench position for optimized performance or use the manual side-shift and optional hydraulic side-shift for precision trenching near buildings and obstacles. Enhance your skid steer’s capabilities with the Lowe XR-Series Trencher Attachment and achieve reliable, high-quality trenching every time. Perfect for contractors and operators seeking maximum efficiency and power.
| Model | Recommended Flow | Trench Depth | Trench Width |
|---|---|---|---|
| XR-35HP | 20-45 GPM (2,000-4,200 PSI) | 3'-5' | 6"-12" |
SPEED
| Gallons Per Minute | Feet Per Minute | Shaft RPM |
|---|---|---|
| 20 GPM | 222 ft. per minute | 83 RPM |
| 22 GPM | 244 ft. per minute | 91 RPM |
| 24 GPM | 266 ft. per minute | 100 RPM |
| 26 GPM | 289 ft. per minute | 108 RPM |
| 28 GPM | 311 ft. per minute | 116 RPM |
| 30 GPM | 333 ft. per minute | 125 RPM |
| 32 GPM | 355 ft. per minute | 133 RPM |
| 34 GPM | 377 ft. per minute | 141 RPM |
| 36 GPM | 400 ft. per minute | 149 RPM |
| 38 GPM | 422 ft. per minute | 158 RPM |
| 40 GPM | 444 ft. per minute | 168 RPM |
POWER
| PSI | Torque (lbs/ft) |
|---|---|
| 2,000 PSI | 1,475 lbs/ft. |
| 2,500 PSI | 1,844 lbs/ft. |
| 3,000 PSI | 2,212 lbs/ft. |
| 3,500 PSI | 2,581 lbs/ft. |
| 4,000 PSI | 2,950 lbs/ft. |
features
- Advanced Self-Aligning Boom Design: Reinforced boom with a grease cylinder tensioning system enhances durability and boosts performance, perfect for demanding trenching tasks.
- Heavy-Duty Drive Shaft: Built with superior strength and wear-resistant materials to withstand the toughest conditions, ensuring longevity.
- Low-Maintenance Tapered Bearings: Durable tapered roller bearings at the boom tip reduce maintenance needs, saving time and effort.
- Easy Maintenance Access: Designed for quick servicing and fast part replacements, minimizing downtime and keeping productivity high.
- Enhanced End-Boom Roller: New wear-resistant roller reduces bearing load, extends chain life, and prevents lockup for smoother operation.
- Optimized Trencher Housing: Redesigned housing improves visibility, makes trench starts easier, and maximizes overall digging efficiency.
- Durable Optional Trench Cleaner: An upgraded trench cleaner improves cleanout effectiveness and durability compared to previous models.
- High-Pressure LOWE® Hydraulic Motors: Engineered for exceptional strength and reliability under high-pressure conditions for maximum output.
- Proudly Made in the USA: Crafted with American quality for trusted performance and reliability in every job.
