Rock & Concrete Grinder - Excavator | Blue Diamond
Product ID:
BD-EX-CNCRT-GRNDR
BD-EX-CNCRT-GRNDR
Availability:
limited quantity available
limited quantity available
LIMITED TIME FREE SHIPPING!
10% discount applied.
Sale ends December 31, 2024
$29,302.00$26,371.80
Questions?Call 866-315-3134 - Se Hable Espanol
Business financing:
DETAILS
This price includes hoses and couplers (A $450 Value!)
***Please note: Excavator mount pins not included. At checkout, you will be asked to provide the make and model of your machine.
This is a must have tool for contractors who are working in applications where rock, concrete, and asphalt need to be removed. This grinder will grind a clean trench with nice vertical walls. There are 4 different models to choose from based on the weight of your machine and the gallons per minute it produces.
| MODEL | G1S | G1 | G2 | G3 | G3XL | G4 |
|---|---|---|---|---|---|---|
| FLOW RANGE GPM | 5-12 | 8-20 | 12-26 | 30-45 | 34-65 | 50-85 |
| CARRIER WEIGHT LBS | 2,200-6,600 | 4,400 -17,500 | 11K-33K | 26K-44K | 33K-66K | 50K-90K |
| MAX PRESSURE PSI | 5,800 | 5,800 | 5,800 | 5,800 | 11,600 | 14,500 |
| HEAD DIAMETER | 9" | 11" | 16.5" | 22" | 23" | 29" |
| CUTTING WIDTH | 19" | 21" | 25" | 31" | 32" | 44" |
| MAX TORQUE FT/LBS | 1,196 | 2,625 | 4,370 | 8.740 | ||
| MAX CUTTING FORCE LBS | 3,348 | 5,717 | 7,028 | 9,545 | ||
| WEIGHT LBS | 265 | 635 | 1,035 | 2,045 | 2,290 | 4,125 |
features
- All American-made parts and components
- Extremely high torque hydraulic motor
- Powerful cutting drums, ensure maximum production & prolonged life
- Customizable drums to accommodate performance maximized applications
- Strong spur gears and housing
- Bolt-On mount. Allowing for use on both excavators and skid steers
