Tractor 12' Flex Wing Rotary Cutter | Blue Diamond
403150
limited quantity available
LIMITED TIME FREE SHIPPING!
10% discount applied.
Sale ends December 31, 2024
DETAILS
With its smooth top deck and spring suspension, this Flex-Wing Rotary Cutter is ideal for medium-duty applications such as weeds, grass, and brush up to 2” diameter. Designed for use with compact tractors as small as 35 hp, the cutter requires only one hydraulic outlet. For its 144” cutting width, the cutter uses three independent spindles with two free-swinging blades each, to reduce the shock of hitting a stationary object. Slip clutches protect the gearboxes and drivelines from damage. Standard equipment includes driveline shields, clutch shields, chain discharge shields, and a towing safety chain.
MODEL | 12' FLEX WING CUTTER |
---|---|
MINIMUM HORSEPOWER | 35 hp (Gear-drive Trans) |
HITCH | Swivel Clevis |
DECK THICKNESS | 10 GA |
DECK HEIGHT | 11” |
SIDE SKIRT MATERIAL | 3/16” |
HINGE RODS | 1” |
SUSPENSION | Single Spring |
OUTDOOR GEARBOX | 75 HP |
SPLITTER GEARBOX | 175 HP |
GEARBOX | 540 RPM |
BLADES | 1/2” x 3” w/lift |
BLADE TIP SPEED | 15,657 FPM |
BLADE OVERLAP | 6” |
BLADE CARRIERS | 3/16” Formed Plate with 3/4” x 5” x 20” Blade Bar |
features
- Smooth top deck design
- Protected gearboxes and drivelines
- 144” cutting width
- 2-year warranty
- Made in the USA
